What are the inputs represented by FIN, GIN, TIN, and PIN in the wiring diagram of Hongruns 5600 flow integrator? _Baidu Knowledge In Hongruns 5600 flow integrator, the functions of various input ports are clearly distinguished to ensure accurate measurement and data recording. Among them, FIN represents the pulse signal input terminal of the flow meter, which is used to receive pulse signals from the flow meter. GIN represents the linear and differential pressure signal input of the flowmeter, where analog signals are typically used to represent the linear variation of flow rate or pressure difference. The PIN input terminal is designed to compensate for pressure signals and provide more accurate flow measurement results. The TIN input is used to receive temperature signals and further improve measurement accuracy through temperature compensation. Specifically, the FIN port is mainly used to connect pulse flow meters, which are typically used to measure instantaneous flow rates. The GIN port can receive linear and differential pressure signals, where the linear signal reflects the linear variation of flow rate, and the differential pressure signal is used to measure the pressure difference between two pressure points, which is crucial in many flow measurement applications. The pressure compensation signal received by the PIN port helps to correct measurement errors caused by pressure fluctuations, thereby ensuring the accuracy of measurement results. The TIN port is used to connect temperature sensors, and through temperature compensation, measurement errors caused by temperature changes can be further reduced. In summary, the design of these ports fully considers various factors in practical applications, aiming to
2. How to set the small signal cutoff of Hongrun NHR-7600 LCD flow (thermal energy) integrator?
First, you need to determine what signal the flow meter you are using is. If it is an analog quantity (linear, differential pressure), then the percentage cut off is the range (flow before compensation).; For example, if the linear or differential pressure range is 1000 and all values below 24 are displayed as 0, then the amount to be cut off is 24 divided by 1000 and multiplied by 100%. The resulting value can be set in the configuration channel small signal cut off section; If it is a frequency input, then what is cut off is the number of frequencies. For example, when the residual indicator light of the frequency input flow bridge is on, it displays 24. Then, for the medium difference configuration channel small signal cut off, simply set it to 24.
3. Hongrun OHR-C01 Loop Calibration Instrument, with strong endurance, color screen, compact and portable features
Hongrun OHR-C01 Loop Calibration Instrument (presumably in the same series as OHR-C00, with the same core features) is a process signal verification instrument with strong endurance, color screen display, compact and portable features. Its functions and design details are as follows:
1. Analysis of core features: Strong endurance, using rechargeable lithi
