1. Measurement of metal tube float flowmeter

1. Sturdy all metal structure design type float flowmeter

2. Measuring tube indicator designed with independent concept

3. Stainless steel, Hastelloy, titanium materials can be selected.

PTFE material measurement system

4. Low pressure loss design

5. Short stroke and small structure with beam gauges, total instrument height of 250

6. Magnetic coupling structure ensures data transmission and more stable signal attenuation

7. Insulation or heat tracing jacket

8. Vertical, horizontal, and various installation methods are more suitable for different usage scenarios of Qiaozhen

9. Suitable for small caliber and low flow medium flow measurement, reliable operation, low maintenance, long service life 1

1. Low requirements for straight pipe sections 1

2. Wide flow ratio 10:11

3. Dual row large liquid crystal display, optional on-site instantaneous/cumulative flow display, can be backlit 1

4. Single axis sensitive indication 1

5. Non contact magnetic coupling transmission 1

6. All metal structure, suitable for high temperature, high pressure and strong corrosive media 1

7 Can be used in flammable and explosive hazardous environments 1

8. Two wire selection, battery, AC power supply 1

9. Multi parameter calibration function 20. With data recovery, data backup, and power failure protection functions

2. Classification of float flow meters

Often standardized products and special instruments can be classified from different perspectives, such as transparent cone tubes and metal cone tubes according to cone tube materials. According to whether there is rem

ote signal output, it is divided into local indication type and remote signal output type, the latter of which is further divided into two types: electric shock signal and electrical signal. According to the measured fluid, it is divided into liquid, gas, and steam. According to the amount of fluid passing through the float flowmeter, it is divided into full flow and split flow types. Classification of Cone Tube Materials

(1) Transparent Cone Tube Float Flow Meter The most commonly used material for transparent cone tubes is glass. Improper operation of unguided structure instruments when measuring gases can easily shatter glass tubes; It is also made of transparent engineering plastics such as polystyrene, polycarbonate, organic glass, etc., which have the advantage of not being easily broken.

(2) Compared with transparent cone tube float flow meters, metal tube cone tube float flow meters can be used for higher medium temperatures and pressures, and there is no potential danger of glass tube float flow meter cone tubes being crushed.

. The typical structure shown in Figure 3 is an integrated structure of a conical tube and a shell, or a separate structure where the conical tube is inserted into the shell. Changing the flow specification only requires replacing the conical tube with a different cone angle, which is more convenient to use. Classification type based on whether there is remote signal output

(1) Local indication type float flowmeter Some transparent ridge and transparent tube float flowmeters mainly use local indication and are equipped with proximity switches to output flow upper and lower limit alarm signals. Some on-site indicating metal tube float flow meters have the same appearan
