1. Parameter description of glass rotor flowmeter
Glass rotor flowmeter is widely used in chemical, petroleum, light industry, pharmaceutical, environmental protection, food and metrology testing, scientific research and other departments to measure the flow rate of single-phase non leased pulsating fluids (liquids or gases). The corrosion-resistant glass rotor flowmeter has strong corrosion resistance and can detect the flow and noise of acids (except hydrofluoric acid), alkalis, oxidants, and other corrosive gases or liquids. It is suitable for industries such as chemical, pharmaceutical, papermaking, and sewage treatment. Appearance and installation dimensions - Zero defect components for measuring fluids - Material, model, specification, and technical parameters - Glass rotor flowmeter - National standard code - Glass rotor flowmeter - The main measuring components of the glass rotor flowmeter are a vertically installed lower small and upper large conical glass tube dust collector and a float that can move up and down inside. When the fluid passes through the conical glass tube from bottom to top, a pressure difference is generated between the top and bottom of the float, and the float rises under this pressure difference. When the upward force, buoyancy, and viscous lift acting on the float are equal to its gravity, the float is in an equilibrium position. Therefore, there is a certain proportional relationship between the fluid flow rate flowing through the glass rotor flowmeter and the rising height of the float, that is, the flow area of the glass rotor flowmeter. The position
3. The appearance and installation dimensions of LZB - () W/WB series glass rotor flow meters
The appearance and installation dimensions of LZBW/WB series glass rotor flow meters vary depending on the model. The specific information is as follows: LZB3W: diameter size: 26mm, installation hole diameter: 116mm. Interface options: optional leather tube or metal tube connector, quick interface or card sleeve interface. LZB3WB: diameter size: similar to LZB3W, but the overall size is 281mm, 136mm, 50mmLZB4W: diameter size: 281mm, 136mm. 56mm installation hole diameter: 27.5mm interface options: quick interface or card sleeve interface LZB6W: diameter size: 281mm, 136mm, 58mm installation hole diameter: 29.5mm interface Qiaoshi options: metal pipe nozzle, quick interface or card sleeve interface LZB10W: diameter size: 281mm, 160mm, 60mm installation hole diameter: 29.5 Mm interface options: metal tube nozzle, bendable to accommodate draft selection of 140mm Φ 11M10 × 12 Φ 11LZB10WB: diameter size and installation details: similar to LZB10W, but the size may be slightly different. Summary: The appearance and installation dimensions of LZBW/WB series glass rotor flow meters vary depending on the model. When choosing, the appropriate model should be determined according to specific application requirements and installation environment.
