1. What are the types of mass flow meters? 2. Emerson flow meter communication protocol Emerson flow meters mainly use MODBUS communication protocol (based on RS-485 interface), and some models support protocols such as HART and Foundation Fieldbus. The following are specific communication protocol types and configuration methods:

1. Main communication protocol types: MODBUS RTU: Emerson high-precision series mass flow meters and Flexim FLUXUS G601 ultrasonic flow meters both support this protocol, which is used to transmit instantaneous mass flow rate, cumulative quantity and other data.

. • HART protocol: Some transmitter models support HART (superimposed on 4-20mA analog signals) for basic configuration and diagnosis. • Foundation Fieldbus: A few high-end models support this industrial bus protocol

2. MODBUS protocol configuration points • Address mapping: Each device needs to set a unique address (1-247), and register addresses need to be mapped according to the manual (such as mass flow usually stored in hold registers). Communication parameters: baud rate (commonly 9600/19200), odd/even/even parity check (none/even/odd), and stop bit (1/2 bit) must be consistent with the upper positive scrambling bit machine. • Data reading: Read register data through MODBUS command (such as 03/04 function code), CRC check to ensure integrity

3. Model configuration method 1700/2700/9739 transmitter: - Long press SCROLL+SELECT key for 4 seconds to enter menu ->select OFF-LINE MAINT ->enter password (default 1234) ->enter CONFIG COMM to set protocol type and parameters. 3000 series transmitter: - Set protocol address and communication parameters through Management → Configuration → Digital communication → Con

figure RS-485

4. Compatibility and integration - MODBUS protocol can be directly integrated with PLC, SCADA, HMI and other systems without the need for additional conversion modules. -Using Emerson AMS equipment management software can simplify the configuration and monitoring process. If you need a specific models register address mapping table or detailed parameters, you need to refer to the corresponding models user manual (such as Chapter 9 of the high-precision Coriolis flowmeter series manual, which usually includes a MODBUS register list).

3. Size of Emerson Quality Flow Meter 1700

The size of Emerson Quality Flow Meter 1700 varies under different models and configurations, and the size data mentioned in public information is relatively limited.
